IT-100 Installation
Installing a new IT-100 module to link DSC with Control4
Recommended troubleshooting accessories
If your issue involves failing cables, adapters, power delivery, or AV accessories, this Amazon search may help you find compatible troubleshooting equipment.
As an Amazon Associate, AV Knowledge may earn from qualifying purchases.The Issue
Installing a new IT-100 module to link DSC with Control4
Steps to Resolve
Step 1
1. Call central station and put the system in test mode.
Step 2
2. Power off the system at the panel and disconnect IT-100.
Step 3
3. Use same wiring configuration to connect new IT-100 to panel and power cycle system.
Step 4
4. At DSC keypad, enter Section 902 (wait 1 minute) folowed by Section 903.
Step 5
5. IT-100 will show up as Keypad 8
